4.

OPERATION FROM PC

4.1

Installing the PC program

The vtLite Mobile program allows FELCOM 30 to be operated or configured
from a PC, including functions such as:
Phone book
Traffic log
Configuration of ports
(ISDN/RS-232/USB/RS422)
Configuration of the CU
Connect the PC as shown belpw.
The vtLite Mobile program is available on the enclosed CD and must be
installed on the PC hard disk.
For an explanation of the functions, see later in this manual.
Note: To install the vtLite Mobile, the user name of the PC should be one-byte
characters.
ON
48 VDC
SYNC
ALARM
RS-232 A RS-232 B
4 3 2 1 5 4 3 2 1
5
9 8 7 6
9 8 7 6
ISDN
ISDN
USB
ISDN
RS-422
The driver used with
the RS-232 B (DATA)
port can be switched
to be used with the
RS-422 (DATA) port
instead. The switching
is performed with the
ISDN Handset.
USB port
PC serial port
DTE
4-1
