Page 17: Equipment List
EQUIPMENT LIST Complete Set Name Type Code No. Remarks Antenna Unit RSB-0071-058 Display Unit RDP-099-31M3 Spare parts FP03-06000 000-085-153 1 set Accessories SP03-05800 000-080-923 1 set Installation CP03-18000 000-086-968 1 set Signal Cable: 10 m CP03-18010 000-086-969 Signal Cable: 15 m Material CP03-18020 000-086-970... -
Page 62: Mounting The Antenna
(1) This signal cable run between the antenna and the display comes in lengths of 10 m, 15 m, 20 m and 30 m. whatever length is used it must be unbroken; namely, no splicing allowed. (2) Deposits and fumes from a funnel or other exhaust vent can adversely affect the aerial performance and hot gases may distort the radiator portion. - Page 63 Pan head screws M4x8 4 pcs. to one of the screws Cable clamping plate of the cable clamping plate Shield cover Gasket Pan head screws 9-pin connector: M4x8 7 pcs. to J801 on MD-9208 Shield cover Pan head screws 4-pin connector: M4x8 7 pcs.
