Evm Operation - Texas Instruments ADS1282V2EVM-PDK User Manual

Implementation Results
4 Implementation Results

4.1 EVM Operation

4.1.1 Evaluation Setup
Connect the EVM as shown in
1. Physically connect P2 of the PHI to J8 of the ADS1282EVM. Install the included screws to provide a robust
connection.
2. Connect the USB connector on the PHI to the computer.
a. LED D5 on the PHI lights up, indicating that the PHI is powered up.
b. LEDs D1 and D2 on the PHI start blinking to indicate that the PHI is booted up and communicating with
the PC; Figure 4-1
3. Start the software GUI as shown in
is loaded on the PHI. This loading takes a few seconds. LED D1 on the ADS1282EVM illuminates once a
connection has been established.
4. Connect the differential signal generator to the ADS1282EVM inputs. The full-scale input range is ±2.5V
differential with a common mode from 0V to 2.5V. A typical input signal is a 4.8V
signal is adjusted just below the full-scale range to avoid clipping.
5. Verify the default jumper positions of the ADS1282EVM. Jumper JP1 is placed in the UNIPOLAR position
(pins 1-2) by default. Jumper JP3 is placed in the ENABLE position (pins 2-3) by default.
Signal
Source
Signal
Source
4. Connect signal
sources to inputs
14 ADS1282EVM-PDK Evaluation Module
Figure 4-1 after installing the software:
shows the resulting LED indicators.
Figure 4-2. Notice that the LEDs blink slowly when the FPGA firmware
5. Verify default jumper
Op
posi o ns:
£
connect -5V to -3V supply for
JP1, UNIPOLAR
JP3, ENABLE
Figure 4-1. Connecting the Hardware to the ADS1282EVM
Figure 4-2. Launch the ADS1282EVM GUI Software
Copyright © 2024 Texas Instruments Incorporated
o nal: Populate J6 and
¤
bipolar opera o n
¥
LEDs, D1, D2, and D5.
LED D1 lights up when
connec
¡
established
1. Connect PHI to
ADS1282EVM and
install screws
Select EVM GUI from
Start menu or
desktop shortcut
sinusoidal wave. This
PP
o n with EVM is
2. Connect USB cable to
worksta on
3. Start so w are GUI
¢
SBAU431 – JULY 2024
