Hardware Design Files
Designator Quantity
R1, R2, R9, R11,
R13, R18, R38, R39, 11
R42, R43, R66
R3, R4, R7, R8 4
R5, R6 2
R10, R14, R16, R17,
R19, R20, R23, R24,
13
R25, R26, R27, R63,
R65
R12 1
R15 1
R21, R45, R52, R53,
7
R54, R56, R64
R22 1
R28, R29, R36, R37 4
R30, R33 2
R31, R34 2
R40 1
R41, R67 2
R44 1
R46, R49, R50, R51 4
R55 1
SH-J1, SH-J2 2
28 ADS1282EVM-PDK Evaluation Module
Table 5-1. Bill of Materials (continued)
Value Description
0 RES, 0, 5%, 0.1 W, 0603
RES, 221, 1%, 0.25 W, AEC-Q200 Grade 0,
221
1206
20.0k RES, 20.0 k, 1%, 0.1 W, 0603
49.9 RES, 49.9, 1%, 0.063 W, 0402
CRCW Thick Film Commodity Chip Resistor
0 Jumper 0603 Size 0 Ohm 0.1 W 2-Pin SMD
Paper T/R
RES, 0.22, 1%, 0.1 W, AEC-Q200 Grade 0,
0.22
0603
10.0k RES, 10.0 k, 1%, 0.1 W, 0603
Res Thick Film 0603 120K Ohm 1%
120k
0.1W(1/10W) ±100ppm/C Pad SMD T/R
1.00k RES, 1.00 k, 1%, 0.1 W, 0603
Res Thick Film 0603 15 Ohm 1%
15 0.1W(1/10W) ±100ppm/C Pad SMD
Automotive T/R
10 Ohms ±0.5% 0.1W, 1/10W Chip Resistor
10
0603 (1608 Metric) - Thin Film
2.0k RES, 2.0 k, 5%, 0.1 W, 0603
RES, 82 k, 5%, 0.1 W, AEC-Q200 Grade 0,
82k
0603
11.3k RES, 11.3 k, 1%, 0.1 W, 0603
RES, 0, 5%, 0.063 W, AEC-Q200 Grade 0,
0
0402
37.4 RES, 37.4, 1%, 0.1 W, 0603
1x2 Shunt, 100mil, Gold plated, Black
