6 EVM Setup and Operation

This section includes the setup and operation of the EVM for parameter performance evaluation. Typical
waveforms are included.

6.1 Overview

The basic setup in Figure 6-1
on one side and 5-V on the other. If both sides are to be evaluated at the same supply voltage, only one power
supply is required and can be used to power both sides of the EVM.
Note that this EVM is for operating parameter performance evaluation only and not designed for
isolation voltage testing. Any voltage applied above the 5.5-V maximum recommended operating
voltage of the ISO721 will damage the EVM.
Tektronix
HFS9009
Pattern
Generator
The input to the EVM is a 20-MHz pulse displayed on channel 1 in
2.

7 Revision History

NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
SLLU091A – JANUARY 2006 – REVISED SEPTEMBER 2022
Submit Document Feedback
has the two power supplies required to evaluate isolator performance with 3.3-V
CAUTION
Power Supply
P 1 P 3
J 3
Vcc 1 GND 1
INPUT

Figure 6-1. Basic EVM Operation

Figure 6-2. Typical Input and Output Waveforms
