Compressor inverter

Advertisement

Notes:
(1)
Current derating may apply at high grid voltage.
(2)
Switching Frequency range 2.0kHz ÷ 5.0kHz with derating
(3)
Max altitude (
TN-S, TN-C, TN-CS, TT systems
derating every 100m.
(4)
Max altitude (
): 2000m with no derating; for installation over 2000m please contact your Daikin Applied
IT systems
representative for instructions.
The VFD is designed to be used in TN (grounded neutral point) networks. If installing the VFD in other types of
grounded systems, contact your Daikin Applied representative for instructions. See Par. 7.2 for more details.
OTHER INFORMATIONS (FOR UL STD 60730-1 / CSA STD E60730-1)
-
Purpose of control: protective control
-
Construction of control: incorporated control
-
Action: Type 2.C
-
Rated impulse voltage: 4000V

5 TRANSPORTATION

5.1 Introduction

Lifting and handling operations must be carried out exclusively by specialized and trained personnel with
the fitness to perform these activities.

5.2 Handling

The handling activities described in this paragraph must be carried out by qualified personnel for such operations:
personnel specially trained to safely carry out loading, unloading and handling operations using lifting equipment,
and who is aware of the rules of accident prevention.
5.2.1

GROUP AND WEIGHT DIVISION TABLE

Follow the table below to see in which and how many separate parts the equipment will be transported.
GROUP
Automation Inverter PE-ADDA200
5.2.2

Transport operations

Given the weight of the equipment (greater than 25 kg), transport and handling must be carried out with the
collaboration of at least two operators. Alternatively, a pallet truck or forklift is required.
The personnel in charge of lifting operations must be authorized and trained in the use of equipment and
lifting means, and must comply with the requirements for individual protection.
Daikin Applied Europe S.p.A
SERVICE and INSTALLATION MANUAL
Compressor Inverter PE-ADDA200
): 2000m with no derating; up to 3000m with 1% rated output current
WEIGHT
35 kg
Page 11 of 51
Rev. 0.3
Packaging Dimensions
[mm
3
]
800x605x290
