4 TECHNICAL DATA

4.1 Specification

Line Reactor (external)
Rated Input Current
True Power Factor @ rated load
THDi @ rated load (25kA Isc)
Rated Output Current
Switching Frequency
Min. electrical frequency
Weight Inverter[kg]/Capacitor Bank [kg]
Packaging Dimensions [mm3]
I2t (value for fusing)
Temperature range (operation)
Temperature range (storage)
Environment (EN60664-1)
Enclosure protection degree
Daikin Applied Europe S.p.A
SERVICE and INSTALLATION MANUAL
Compressor Inverter PE-ADDA200
Tab. 2 Inverter Specification
Description
Power Supply
Mains Unbalance
(1)
(2)
@ full load
Max Power Loss
Tvj=45°C, VR=0
Max Overload
Output Frequency
Output Voltage
Relative Humidity
(not condensing)
Cooling
Expected life time
Max Altitude (3)
Page 10 of 51
PE-ADDA200
380...480Vac±10%; 50/60Hz±5%
Max 2% of rated supply voltage
59 µH
420 A
0.9
36%
440 A
4.0 kHz
20Hz
4 kW
25 / 10
800 X 605 X 290
410 kA²s
No overload
0...400 Hz
0...0.94 Vin
−10...+55 °C
−10...+60 °C
5%-95% RH
Overvoltage category III,
Pollution degree 2
IP54
Expanded Liquid Refrigerant Cooling
100 kh
3000 m
(TN-S, TN-C, TN-CS, TT neutral earthed systems)
2000 m
(IT systems)
Rev. 0.3
(4)
