ALARM
HEX DEC
Motor I2t
A.6.0.H A6.0 thermal
excessive current absorption for an
alarm
Auto- tuning
A.7.0.H A7.0 test
unfinished
Watchdog
A8.1 alarm
A.8.1.H
LogicLab
Fast task
The logicLab fast task is too long in
A.8.2.H A8.2 LogicLab too
long
Application
A.8.3.H A8.3 out of
service
Overspeed
(more than
A.9.2.H A9.2 10
consecutive
Tpwm)
A.9.6H A9.6 The actual speed estimated differs too
Speed
much from speed reference
Control Lost
DC Bus
under
A.A.0.H A10.0 minimum
threshold
admitted
Emergency
A.A.1.H A10.1
braking
A.b.2.H A11.2 DC
Overvoltage
SW detection
Daikin Applied Europe S.p.A
SERVICE and INSTALLATION MANUAL
Compressor Inverter PE-ADDA200
DESCRIPTION
The motor electronic overload
safety switch has cut in due to Check the thermal current setting, and correct if necessary (P70).
extensive period.
The RUN command was disabled
during a test. Run command Reset the alarms and repeat the test by re-enabling it.
switched off too early.
A LogicLab watchdog alarm on
slow cycle appears
time
There is no valid application
running in the VFD
Overspeed: speed reading higher
than threshold set in P51
Probably the sensorless looses control. If the threshold P56 is very
low, increase its value
Intermediate VFD circuit voltage
(DC Bus on capacitor bank :
possible to read on d24) has
powerful enough to sustain the loads or when powerful motors
dropped below the minimum value
(P106).
Emergency braking/ main supply Investigate why main power is lost during operation motor
lost
Intermediate VFD circuit voltage
(DC Bus see d24) has exceeded the
maximum value (P107).
Page 47 of 51
CORRECTIVE ACTION
Check the motor load. Reducing it may prevent the safety
switch cutting in.
Check that the heat constant value is long enough (P71). Check
that the safety heat curve suits the motor type and change the
curve if necessary (C33).
Check if the LogicLab slow task duration is greater than 500
ms and try to reduce this execution time
Try to reduce the LogicLab fast task execution time under
admitted limit.
Please refer to the specific documentation.
Reload the application using VFDNav
In a transient state, the speed reading has exceeded the
permitted limit. Adjust the speed regulator gains or raise the
limit in P51.
Note: in case of A3.0 alarm, control board (for major safety)
removes enable to the precharge card,
so capacitor bank discharged and alarm AA0 appears.
Undervoltage may occur when the mains transformer is not
are started up on the same line.
Try to stabilise the line by taking appropriate measures. If
necessary, enable the BUS support function for mains failure
(C34=1). This however can only help motors with light loads.
An overvoltage in the mains may also trigger the safety
switch.
Rev. 0.3
Contact FACTORY
Not applicable
Contact FACTORY
Contact FACTORY
Contact FACTORY
Contact FACTORY
Contact FACTORY
Contact FACTORY
