9.2 VFD Protections – VFDNav service software required
The VFD includes the following protections:
VFD Current Overload
VFD Over Current with solid state short circuit protection
VFD Heatsink High Temperature
Under Voltage
Over Voltage
Motor High Temperature: VFD measure PTC on motor and pass value to control system and this define
the limit
Safe Torque Off
9.3 VFD Overload/Over Current - VFDNav service software required
VFD output current is constantly measured in all three phases. Different thresholds are integrated into the
inverter, that lead to different alarm conditions.
Extremely high currents may cause a hardware fault to the power board. In this case an A3 alarm will be
generated.
Level
Description
Hardware overcurrent
Phase-U IGBT desaturation
Phase-V IGBT desaturation
1
Phase-W IGBT desaturation
Software overcurrent
Electronic differential
2
Motor Thermal Current (I2t)
Motor Thermal Time Constant
3
VFD min current
Min current waiting time
Daikin Applied Europe S.p.A
SERVICE and INSTALLATION MANUAL
Compressor Inverter PE-ADDA200
Tab. 9
Parameter
Value
120%Imax
P37
110% Imax
P127
10% Imax
P70
110% In
P71
180 s
P244
5% In
P243
2 s
Page 40 of 51
Action
A3.0 Alarm. VFD Stops
A3.1 Alarm. VFD Stops
A3.2 Alarm. VFD Stops
A3.3 Alarm. VFD Stops
A3.4 Alarm. VFD Stops
A3.5 Alarm. VFD Stops
A6.0 Alarm. VFD Stops.
A4.4 Alarm VFD Stops.
Rev. 0.3
