To load the desired alarm log, press the corresponding "Load trace" button and wait the end of automatic
procedure: SoftScope is opened and data related to alarm log are loaded.
Press "Show all values" button to visualize the trace entirely.
 In SoftScope save the log with the "Save as" command in the Menu, specifying the name TraceAlarm1

In VFDNav execute "Parameters\Read all" command from the Menu and at the end save the project with
"Save as" command specifying the name LogAlarm1.
Repeat these steps starting from 'press "Load trace button"' to save all the existing alarm logs.
Daikin Applied Europe S.p.A
SERVICE and INSTALLATION MANUAL
Compressor Inverter PE-ADDA200
Fig. 31
