10. INSPECTION

The inspection should be conducted once every 6 months to a year.
Any inspected items which do not satisfy the criteria shown below should be repaired
Inspection
item
Measure the voltage fluctuation at the power
Power
supply terminal block of the converter to
supply
determine if it is within the prescribed range.
Ambient Check the ambient temperature.
Conditions
There should be no accumulation of dust.
Verify that the sensor is securely mounted.
Verify that the sensor rod is securely coupled
to the machine.
Mount Check for severed cables.
Conditions Verify that the sensor cable connector is
plugged in all the way.
Verify that the SSI connector is plugged in all
the way.
*1: For CYLNUC Cylinder and CYLNUC MarkⅡ Cylinder, contact your NSD representative.
Inspection Description Criteria
Within 21.6V to 26.4VDC range
ABSOCODER sensor
VLS-12.8PRA28: -20 to +120℃
VLS-12.8MHP28: -20 to +120℃
IRS-51.2P: -20 to +120℃ *1
IRS-32.8P: -20 to +120℃
Converter: 0 to +55°C
None
There should be no looseness.
There should be no looseness.
Cable should appear normal.
There should be no looseness.
There should be no looseness.
40
Remark
Tester
Thermometer
Visual
Inspection
