3. SPECIFICATIONS

3-1. Converter Specifications

3-1-1. General specification

Items
Power supply voltage
Power consumption
Insulation resistance
Withstand voltage
Vibration resistance
Ambient operating temperature
Ambient operating humidity
Ambient operating environment
Ambient storage temperature
Grounding
Construction
Outside dimension (mm)
Mass

3-1-2. Performance specification

Items
Applicable sensor
Resolution
Total number of divisions
Position detection format
Communication interface
Number of communication
channels
Output code
Number of detection axes
Position data sampling time
Position data increase direction
Front panel function
Switch
(on rear face of product)
Monitor LED
Input signal
Output signal
Applicable standard
24VDC±10% (including ripple)
10W or less
20 M-Ohms or more between external DC power terminals and ground
(by 500 VDC insulation resistance tester)
500 VAC, 60Hz for 1 minute between external DC power terminals and ground
20m/s 10 to 500Hz, 10cycles of 5 minutes in 3 directions,
2
conforms to JIS C 0040 standard
0 to +55°C (No freezing)
20 to 90 %RH (No condensation)
Free from corrosive gases and excessive dust
-25 to +70℃
Must be securely grounded (ground resistance of 100 ohm or less)
Book-shelf type within enclosure, DIN rail mountable
39(W) x 155(H) x 93(D) Refer to dimensions for details.
Approx. 0.4kg
CYLNUC Cylinder
VLS-12.8PRA28
VLS-12.8MHP28
1.5625μm
(12.8mm/8192)
Standard pitch x number of pitches (8192 divisions (2
Semi-absolute format
SSI (Synchronized Serial Interface)
2ch
Binary or gray code (switchable)
2
0.2ms
CW or CCW (switchable)
Zero point setting, error clear
Position data increase direction setting (CW / CCW)
Output code (binary /gray)
Axis-2 error detection (enable / disable)
Display of position data, power supply status, sensor disconnected error,
sensor data error, low power supply error, memory error, converter error
Axis-1 zero point setting: 1-point
Axis-2 zero point setting: 1-point
Error clear signal: 1-point
Axis-1 system ready signal: 1-point
Axis-2 system ready signal: 1-point
CE Marking (EMC directive)
6
Specifications
Specifications
CYLNUC MarkⅡ Cylinder
IRS-51.2P
6.25μm
(51.2mm/8192)
) x max. 2048 pitches)
13
IRS-32.8P
4μm
(32.8mm/8192)
