NSD ABSOCODER NCV-220HSSILC Specifications & Instruction Manual page 40

(6) Parameter switch (Rear face)
The switch status is set as the parameter when the power supply turns ON.
The operation isn't influenced even though the switch is changed during the operation.
Switch
Parameter name
No.
Axis-1 position data
1
increase direction
Axis-2 position data
2
increase direction
3 Axis-1 output code
4 Axis-2 output code
5 Reserved
6 Reserved
7 Reserved
Axis-2
8
(enabled / disabled)
*1: The position data increases or decreases according to the ABSOCODER sensor's rod travel direction.
Switch setting
ON : CCW Specify the direction in which the axis-1 position
OFF: CW data should increase. *1
ON : CCW Specify the direction in which the axis-2 position
OFF: CW data should increase. *1
ON : Gray Outputs Axis-1 position data in the gray code
OFF: Binary when the setting is ON.
ON : Gray Outputs Axis-2 position data in the gray code
OFF: Binary when the setting is ON.
Keep this switch in the OFF position.
Fixed at OFF The correct operation cannot be guaranteed if this
switch is set to the ON position.
Keep this switch in the OFF position.
Fixed at OFF The correct operation cannot be guaranteed if this
switch is set to the ON position.
Keep this switch in the OFF position.
Fixed at OFF The correct operation cannot be guaranteed if this
switch is set to the ON position.
When this switch is set to the ON position, error
ON : Disable will not occur even if the axis-2 sensor is not
OFF: Enable connected. Axis-2 position data is "0", and monitor
LEDs from 0 to 23 blink.
34
Description
Factory
setting
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
