NSD ABSOCODER NCV-220HSSILC Specifications & Instruction Manual page 17

(3) Rod sensor (VLS-12.8MHP28)
Items
Model
Max. detection stroke
Absolute detection range
Resolution
Linearity error
Head
Mass
Rod
Sliding resistance
Permissible mechanical speed
Ambient Operating
temperature Storage
Ambient operating humidity
Vibration resistance
Shock resistance
Protection rating
Interconnecting cable
Standard cable
Max. sensor
Robotic cable
cable length
JKPEV-S cable
Head
Surface
Rod
Head
Material
Rod
VLS-12.8MHP28-[ ]FA[ ]
1.5625μm(12.8mm/8192)
Max. 0.15 + [stroke (mm)]/5000 mm
6.5 + 0.1 x [ cable length(m)] kg
1 + 0.0048 x [ stroke (mm)] kg
69 N or less (7kgf or less)
2.0 x 10 m/s (20G) 200Hz up/down 4h, forward/back/left/right 2h each,
2 2
conforms to JIS D 1601 standard
4.9 x 10 m/s
3
conforms to JIS C 5026 standard
IP67, conforms to JEM 1030 standard
IP69K, conforms to ISO 20653 standard
JKPEV-S (1.25mm
Electroless nickel plated
Hard chromium electro plated
Steel
Steel
11
Specifications
VLS-12.8MHP28-[ ]LA[ ]
1200 mm
12.8 mm
1000 mm/s
-20 to +120℃
-30 to +120℃
－
(500G) 0.5ms, up/down x 3 times,
2
2・5・10・20m
4P-S 200m
4P-RBT 100m
×5P) 200m
2
Coated (epoxy resin)
Hard chromium electro plated
Cast iron
Steel
