8-2. Function and Name of Display and Setting Area

(1) Monitor LEDs
Name
PWR (green)
GRAY1 (green)
GRAY2 (green)
SE1 (red)
SE2 (red)
ME (red)
PF (red)
WSP (red)
0 to 23 (green)
(2) Axis display selection switch
Selects the position data which is displayed on the monitor LED on the panel.
･ The axis-1 current position data is displayed on monitor LED when the switch is "1".
･ The axis-2 current position data is displayed on monitor LED when the switch is "2".
All LEDs from 0 to 23 blink when the axis-2 is not used.
(3) Error clear button [CLR]
The error display turns OFF by pressing this button [CLR] after removing an error cause. The system ready signal
of the connector output turns ON.
(4) Axis-1 zero point setting button [ZPS1]
Axis-1 position data is set to "0" by pressing this button [ZPS1]. Do this procedure after moving the machine
position to the zero point position (0 position).
(5) Axis-2 zero point setting button [ZPS2]
Axis-2 position data is set to "0" by pressing this button [ZPS2]. Do this procedure after moving the machine
position to the zero point position (0 position).
LED turns ON when the power supply is normal status.
LED turns ON when the axis-1 output code is gray.
LED turns ON when the axis-2 output code is gray.
LED turns ON when the axis-1 sensor is disconnected.
LED blinks when the axis-1 sensor data error.
LED turns ON when the axis-2 sensor is disconnected.
LED blinks when the axis-2 sensor data error.
LED turns ON when the memory has an error.
LED turns ON when the power supply voltage is low.
LED blinks or ON when the converter has an error.
Indicates a position data in a binary code.
The axis-1 position data is displayed when the axis display selection switch is "1".
The axis-2 position data is displayed when the axis display selection switch is "2".
0 to 23 (24-bit)
