8. NOMENCLATURE
8-1. Part Identification
Front face
(1) Monitor LEDs
(6) Parameter switch
Rear face
ON
Power terminal block
(M4 screw)
(2) Axis display
selection switch
(3) Error clear button
(4) Axis-1 zero point
setting button
(5) Axis-2 zero point
setting button
SSI connector
Axis-1 sensor connector
Axis-2 sensor connector
32
