Technical data

Measuring principle
Measuring system
Measured variable
Measuring range
50
16 Technical data
16.1

Application

The measuring device is intended only for the flow measurement of liquids and gases.
Depending on the version ordered, the measuring device can also measure potentially
explosive, flammable, poisonous and oxidizing media.
To ensure that the device remains in proper operating condition for its service life, use the
measuring device only for media against which the process-wetted materials are
sufficiently resistant.
16.2

Function and system design

Mass flow measurement based on the Coriolis measuring principle
The device consists of a transmitter and a sensor.
For information on the structure of the measuring instrument →  10
16.3

Input

Direct measured variables
• Mass flow
• Density
• Temperature
Calculated measured variables
Volume flow
Flow values in SI units
DN
[mm]
1
2
4
8
15
25
40
Measuring range full scale values 
[kg/h]
0 to 20
0 to 100
0 to 450
0 to 2 000
0 to 6 500
0 to 18 000
0 to 45 000
Dosimass IO-Link
to 
min(F) max(F)
