To guarantee IP67 degree of protection, Type 4X enclosure, carry out the following steps
after the electrical connection:
‣
Tighten all device plugs.
7.6
Post-connection check
Is the measuring instrument undamaged (visual inspection)?
Does the supply voltage in the system match the data on the nameplate of the measuring
instrument → 12?
Do the cables used meet the necessary specifications → 26?
Are the mounted cables relieved of tension?
Is the terminal assignment correct → 26?
Is the protective earthing established correctly → 28?
Are the maximum values for voltage and current observed at the IO-Link interface and pulse/
frequency/switch outputs → 51?
Electrical connection
29
