Technical data
Signal on alarm
52
Damping
Pulse/pause ratio
Assignable measured
variables
Switch output
Switching behavior
Number of switching
cycles
Assignable functions
IO-Link
Physical interface
Signal
IO-Link version
IO-Link SSP version
IO-Link device port
The pin assignment deviates from the IO-Link standard to enable compatibility with
previous device versions and installations.
Depending on the interface, failure information is displayed as follows.
Pulse/frequency/switch output
Pulse output
Failure mode
Frequency output
Configurable: 0 to 999.9 s
1:1
• Mass flow
• Volume flow
• Density
• Temperature
• Exciter current
• Oscillation frequency
• Oscillation amplitude
• Frequency fluctuation
• Oscillation damping
• Fluctuation
• Signal asymmetry
Binary, conductive or non-conductive
Unlimited
• Off
• On
• Diagnostic behavior
• Alarm
• Alarm and warning
• Warning
• Limit value
• Mass flow
• Volume flow
• Density
• Temperature
• Totalizer 1-3
• Oscillation damper
• Flow direction monitoring
• Status
• Partially filled pipe detection
• Low flow cut off
According to Standard IEC 61131-9
IO-Link digital communication signal, 3-wire
1.1
Identification and Diagnosis, Measuring and Switching Sensor (as per SSP 4.3.4)
IO-Link port class A
Choose from:
• Actual value
• No pulses
