8 - How to use Configurations

8.16 OID Conversion

This section converts OID property data to send to the device. For constructing the OID see D998200383

DynaFlex Family Programmer's Manual (COMMANDS) for possible combinations of data.

1) Select

tab and select the

menu. Select a desired setting and enter the

TOOLS

OID CONVERTER

appropriate data in the

Data

text box, and then press the

Convert

button.

2) The OID conversion will be shown in the

box. Select the

option and then press the

Result

Set

Send To Device

button to send the converted OID to the device. Reset the device if necessary.

3) Observe the result in the

Output

log.

DynaFlex, DynaProx| Utility | User Manual (Windows)

Page 49 of 80 (D998200402-704)
