2 - How to Connect to Devices Using DynaFlex Utility

2 How to Connect to Devices Using DynaFlex Utility
To connect via an interface listed in the
2.1

How to Connect Using the USB Connection

1) For best results, use the cable that is included with the device.
2) Connect the USB-C end of the cable to DynaFlex device.
3) If you plan to route the cable out the back of the device, route the cable through the cable
management clip to change its direction. Even if you are not routing out the back, you may use the
cable clip for strain relief, to help stabilize the mechanical connection when cardholders or operators
move the device or the cable.
4) Route the cable in the desired direction (e.g., out the back, left, right, or down into the countertop).
5) Connect the other end of the USB cable to the host's USB port.
6) As soon as the device starts receiving power through USB, it automatically powers on.
DynaFlex, DynaProx| Utility | User Manual (Windows)
Connection Type
Figure 2-1 - Connecting DynaFlex to a USB Host
Page 11 of 80 (D998200402-704)
box, follow these steps.
