8 - How to use Configurations
8.6

Send Bitmap Images (LCD Device Only)

Before uploading the image to the device, follow these simple instructions to create device-ready bitmap
images.
a) In a design program, set the canvas size to 320x240 pixels at 72 ppi/dpi
b) Images must be BMP format, 160KB or smaller with no compression, maximum 320px by
240px, with color depth 16 color, 256 color, 16-bit color, or 24-bit color. Images smaller than the
maximum size are centered on the display. Note images at full screen size must be 16-bit color or
lower to meet the size requirement.
For details see D998200383 DynaFlex Family Programmer's Manual (COMMANDS)
To send bitmap image files, follow these steps.
1) Select the USER INTERFACE
slot (1 to 4) to which the image will be sent, and then press the
ID
image file.
2) Select the bitmap image to be loaded to the device, then press the
3) Follow the same instruction to load the images to other slots.
4) To set which slot is to be used for the idle image, select the
then select the slot to be shown as the idle image, and press the
DynaFlex, DynaProx| Utility | User Manual (Windows)
menu, select Send Image
Page 38 of 80 (D998200402-704)
in the Action list, then select the
button to browse for the
Set
Open button.
in the
Set Display Image
Set button.
menu,
Action
