Raption 200 Installation Manual
7
GENERAL SPECIFICATIONS
Compliance
Enclosure rating
Enclosure material
Operating temperature
Ambient temperature storage
Operating humidity
DISPENSER
Network connection
Interface protocol
RFID system
Display HMI
Power limit control
Cable length
Lights for status indication
Dimensions (D x W x H)
Weight
Operational noise level
Wireless Communication EU
AC Meter
57
CE / Combo-2
(DIN 70121; ISO15118)
IEC 61851-1; IEC 61851-23;
IEC 61851-21-2
CHAdeMO compatible
IP54 / IK10
Stainless steel
-30 ºC to +50 ºC
-40 ºC to +60 ºC
5% to 95% Non-condensing
Ethernet 10/100BaseTX
OCPP 1.5 or OCPP 1.6J
ISO / IEC14443-1/2/3
MIFARE Classic
8" anti-vandal colour touchscreen
By software
4 m (all cables)
RGB colours indicator
470x470x2070mm (without cable engaged)
102 kg
Not perceptible
4G LTE /WiFi Hotspot/GPRS/GSM
Compliant with the EN 50470-1 and EN 50470-3 (MID
European standards) or IEC 62052-11
