Raption 200 Installation Manual
2 - Wiring connection for the Dispenser- Scheme - :
49
2
DC #1
2
DC #2
1
PE
3
L + N + PE
1
ETHERNET CABLE
Recommended Ethernet cable type:
S/FTP Cat5e
Must be connected according to T568A regulation.
