Raption 200 Installation Manual
DISPENSER FOUNDATION MEASUREMENTS
TYPE OF TERRAIN
SOFT
COMPACT
VERY COMPACT
VERY COMPACT AND CONCRETE
SLAB
Note:
The figures in this table are for reference use only. The mechanical caracteristics
of the soil (Ck) and the final dimensioning of the concrete base must be performed by
qualified personnel and in compliance with the local regulations of civil engineering works.
29
Hz
ORIENTATIONAL FOUNDATIONS FOR RAPTION 200 DISPENSER
Ck
(kg/cm
)
2
5
12
20
20
FOUNDATION SIZE
(Az x Bz x Hz) cm
65 x 65 x 65
For example vegetal not compact terrain
55 x 55 x 55
For example mix vegetable land with
engraved compactors
55 x 50 x 50
For example mix sand ground with very
compacted and paved gravel asphalt
55 x 45 x 40
Minimum slab edge 10cm of concrete
HM - 100
Bz
COMMENTS
