Raption 200 Installation Manual
Locate the connection points in the Dispenser:
3
51
2
1
Connection to the single-phase
power supply
1
L L
N N
1 1
2
Ethernet
3
DC power supply
CCS+
CCS+
DC-
DC-
P P
E E
CHA+
CHA+
PE
PE
