Circontrol Raption 200 Installation Manual page 5

Here's your guide to
install your Raption 200
4 — Installation
A - Minimum distances of Dispenser
B - Minimum distances of Power Unit
C - Minimum distances between Power Units
D - Fixing
5 — Wiring
A - Power Unit
B - Dispenser
C - Wiring section
D - AC electric cabinet
6 — Last steps
A - Verification
B - How to use and configure
7 — Technical data
8 — Need help?
21
21
22
23
24
39
41
49
53
54
55
55
55
57
59
