AC electric cabinet
D
It is mandatory to install next protections upstream the Charge Point.
MCCB:
The installation of a circuit breaker is required to protect the equipment from
overcurrents and to allow load disconnection. This element shall be a 400 A three-pole
moulded case circuit breaker for each power unit.
Example: Legrand DPX³ 630 MT 3P 400A circuit breaker.
Residual current relay:
Type B differential protection is required in the installation in order to protect the
equipment. As the chargers have a high current, it is better to opt for protection relays
and type B differential transformer toroids rather than circuit breakers.
These relays can also activate a relay output which activates the coil of the circuit
breaker.
Example: RGU-10B relay and WGB residual current transformer.
Overvoltage protection:
The installation company shall provide a suitable overvoltage protection device to
reduce the overvoltage category to category II.
The data in this section are for reference use only.
The final dimensioning of the protection devices in the
installation must be performed by qualified personnel
and in compliance with the local regulations.
