RIT function
The RIT function shifts the receive frequency to
compensate for an off frequency or frequency drift.
The RIT function does not affect the transmit fre-
quency.
Push the [RIT] switch to activate the RIT function.
e "RIT" appears.
Preamp
The preamp is useful under the following conditions:
— When a receive signal is weak.
— When poor propagation conditions exist.
Push the [PREAMP/ATT] switch 1 time to activate
the preamp.
e If "ATT" appears, push 2 times.
e "PREAMP" appears.
Attenuator
The attenuator is useful to prevent the receive signal
from distorting under the following conditions:
— When strong signals are near the desired fre-
quency.
— When strong signal stations are near your loca-
tion.
Noise blanker
The noise blanker reduces click noise generated by
vehicle ignition systems, etc.
Push the [NB] switch to cancel the noise blanker.
e "NB" appears.
Squelch function
For quiet standby, the squelch mutes noise when no
signal is received. Though squelch operates in all
modes, it is particularly useful for FM mode.
Rotate the [SQL] control to the 12 o'clock position to
mute noise, if required.
e When the [SQL] control is rotated too far clockwise,
weak signals cannot be received.
OPERATION 3
Rotate the [RIT] control.
+0 kHz
Decreases [ © Increases
— 1.2 kHz +1.2 kHz
Push the [RIT] switch again to cancel the RIT func-
tion.
e "RIT" disappears.
Push the [PREAMP/ATT] switch 2 times to cancel
the preamp.
e "PREAMP" disappears.
GY NOTE: When a receive signal is not weak, cancel
the preamp. Otherwise, a suddenly appearing
Push the [PREAMP/ATT] switch 2 times to activate
the attenuator.
e If "PREAMP" appears, push 1 time.
e "ATT" appears.
Push the [PREAMP/ATT] switch 1 time to cancel the
attenuator.
e "ATT" disappears.
Push the [NB] switch again to cancel the noise
blanker .
e "NB" disappears.
Y NOTE: To prevent the receive signal from dis-
torting, cancel the noise blanker when click noise
, is not received.
When the squelch is not required, rotate the [SQL]
control to the max. counterclockwise position.
Recommended position
O [SQL]
) Deep
Squelch open
position
