SHIMMING FRAME SUPPORT RAILS / ADJUSTING LEVELERS

1. Cases With Levelers: Adjust
• Important! For cases with casters, after case is in
proper position, levelers must then be
LOWERED to floor.
• Adjust case so it is level and plumb.
• You may need to remove front and/or rear
toe-kick to access levelers.
• Use adjustable wrench (and possibly a pry bar) to
adjust leveler.
• Do not use pry bar on toe-kick (it may buckle).
• Do not use pry bar on end panel (it may chip).
• Use pry bar ONLY on base frame to avoid
damaging case.
• Use a block to reach base frames with pry bar.
• See below illustrations.
Leveler
2. Sealing Cases
• If the case is installed and intended to be sta-
tionary, a generous bead of food grade silicone
sealant along the bottom of the front toe-kick
and rear panel is needed.
• When properly applied, this food grade silicone
sealant will prevent water from seeping to the
floor as well as crumbs and other residue from
entering beneath the case.
Base Frame
Adjustable
Wrench
7
Pry Bar
