OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING / PLUGS - PAGE 1 of 3

OVERVIEW
• These Structural Concepts merchandisers are designed
to merchandise packaged products at 41°F (5°C) or less
product temperatures.
• Refrigerated Display cases are classified by "test Room
Climate Class." Test Room Climate Class 8 is to be
operated in a environment of 24°C (75.2°F) 55% R.H.
• Cases should be installed and operated according to this
operating manual's instructions to ensure proper
performance. Improper use will void warranty.
• Component parts shall be replaced with like components.
NSF/ANSI TYPE II ENVIRONMENTAL CONDITIONS
• This unit is designed for the display of products in
ambient indoor store conditions where temperature and
humidity are maintained within a specific range.
• NSF/ANSI Type II Conditions: Product is displayed in
store conditions with maximum ambient temperature of
80 °F (27 °C) and maximum relative humidity of 55%.
ATTENTION
CONTRACTORS
WARNING
ELECTRICAL
HAZARD
WARNING
KEEP
HANDS
CLEAR
WARNING
HOT
SURFACE
This equipment MUST be installed in compliance with all applicable NEC,
federal, state and local electrical and plumbing codes.
Risk of electric shock. Disconnect power before servicing unit.
CAUTION! More than one source of electrical supply is
employed with units that have separate circuits.
Disconnect ALL ELECTRICAL SOURCES before servicing.
WARNING: This product can expose you to chemicals, including
Urethane (Ethyl Carbamate), which are known to the state of
California to cause cancer and birth defects or other reproductive
harm. For more information go to P65Warnings.ca.gov.
WARNING: Hazardous moving parts. Do not operate unit with covers
removed. Fan blades may be exposed when deck panel is removed.
Disconnect power before removing deck panel.
Disconnect and allow to cool before cleaning or removing from case.
Risk of fire or explosion. Flammable refrigerant is used in this case.
Consult repair manual/owner's guide before servicing this product.
To minimize risk of possible ignition due to incorrect parts or improper service,
this case is ONLY to be serviced by factory authorized service personnel.
The flammable refrigerant type specified on case nameplate is on serial label.
COMPLIANCE
• Performance issues when in violation of applicable NEC,
federal, state and local electrical and plumbing codes are not
covered by warranty. See below.
WARNINGS/DANGER
• This sheet contains important warnings to prevent injury or
death. Please read carefully!
REFRIGERANT DISCLOSURE STATEMENT
• This equipment is prohibited from use in California with any
refrigerants on the "List of Prohibited Substances" for that
specific end-use, in accordance with California Code of
Regulations, title 17, section 95374.
• This disclosure statement has been reviewed and approved
by Structural Concepts and Structural Concepts attests, under
penalty of perjury, that these statements are true & accurate.
COMPLIANCE
WARNING
WARNING
Condensate Pan is Hot!
DANGER
3
