M O B I L E
MULTI-PURPOSE SELF-SERVICE MERCHANDISER
OPEN REFRIGERATED SELF-SERVICE MERCHANDISER
Model MP48
50 1/2*"L* x 45 1/4"D x 50 3/4"H
*Includes end panels.
I:\Oper Manuals\Oasis\MP48_99355.pub
READ AND SAVE THESE INSTRUCTIONS
INSTALLATION &
OPERATING MANUAL
S E R I E S
888 E. Porter Road · Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com
PN 99335
Rev C: 8.24.2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OASIS MOBILE Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Structural Concepts OASIS MOBILE Series

Summary of Contents for Structural Concepts OASIS MOBILE Series

  • Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLATION & OPERATING MANUAL PN 99335 M O B I L E S E R I E S OPEN REFRIGERATED SELF-SERVICE MERCHANDISER MULTI-PURPOSE SELF-SERVICE MERCHANDISER Model MP48 50 1/2*”L* x 45 1/4”D x 50 3/4”H *Includes end panels.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS OVERVIEW AND WARNINGS …..…………………..………….………..…….…………..….. REMOVAL FROM SKID AND CASE PLACEMENT ……….…………………………………... START-UP AND OPERATION ...…….. …..…..…………………...………...…..……………… MAINTENANCE ………...………………………..……………………………..………………….. SERIAL LABEL LOCATION & INFORMATION LISTED / TECH INFO & SERVICE ………... ILLUSTRATED PARTS BREAKDOWN…………….………………………………………..…... CLEANING SCHEDULE ..…………….……………….……………………………….…………. TROUBLESHOOTING ..……………………………….…………………...………………….…. WARRANTY …………...……………………………………………………..……………………..

  • Page 3: Overview And Warnings

    OVERVIEW AND WARNINGS OVERVIEW • The Structural Concepts Oasis self-service cases are designed to merchandise packaged bakery products. • These cases should be installed and operated according to the following instructions to insure proper performance. • This unit is designed for the display of products in ambient store conditions where temperatures and humidity are maintained at a maximum of 75°...

  • Page 4: Removal From Skid And Case Placement

    REMOVAL FROM SKID AND CASE PLACEMENT 1. Remove Unit From Skid 2. Case Placement Caution: case must always remain supported Position case in close proximity to a certified or center of gravity may allow case to fall. electrical outlet with ground. Remove caster shipping blocks.

  • Page 5: Start-Up And Operation

    START-UP AND OPERATION Merchandiser Start-Up • Plug cord into a certified electrical outlet with ground. • Turn on the main power. Switch is on the rear right hand side of base. Supply power will turn on the lights. First time lighting may require a short warm up period for the bulbs.

  • Page 6: Maintenance

    MAINTENANCE Shelf Assembly Removal • Shelves can be removed for cleaning Shelf Bracket or adjustments • For lighted shelving, unplug the light cord. Remove cord from rear rack sup- port harness support. • Remove rear rack support. Rear Shelf • Shelf Assembly Slide shelf slightly back then lift shelf Support...

  • Page 7: Serial Label Location & Information Listed / Tech Info & Service

    • For additional technical information and service, see the TECHNICAL SERVICE page in this manual for instructions on contacting Structural Concepts’ Technical Service Department. • See images below for samples of both refrigerated and non-refrigerated serial labels.

  • Page 8: Illustrated Parts Breakdown

    ILLUSTRATED PARTS BREAKDOWN...
  • Page 9 PARTS LIST Light Assembly, Case Top Casters, Locking Retaining Pin Ballast Retaining Ring Bag Holder Acrylic Ends Work Ledge Light Assembly, Shelving Door Track, Lower Sign Channel Door, Sliding Bulb Rear Shelf Support Shelf Bracket, Upper Door Track, Upper Front Glass Assembly Top Board Shelf Bracket, Lower End Panel (LH)

  • Page 10: Cleaning Schedule

    CLEANING SCHEDULE AREA TO BE CLEANED FREQUENCY INSTRUCTIONS Case Exterior Daily Glass: Clean front (curved) glass and side glass with a household or commercial glass cleaner and a soft cloth or paper towel. Daily End Panels (Acrylic): Clean with a mild soap and water solution and a soft cloth.

  • Page 11: Troubleshooting

    TROUBLESHOOTING CONDITION TROUBLESHOOTING Case Lights Not Working Check that ALL of the light cords are plugged in. Turn lights off and then check bulbs for proper connection. Check that Light Switch (if applicable) is in the on position. Check for burned out bulbs. Turn lights off & replace. Clean dirt and dust from the bulbs to prevent flickering.

  • Page 12: Warranty

    WARRANTY All sales by Structural Concepts Corporation (SCC) are subject to the following limited warranty. “Goods” refers to the product or products being sold by SCC. Warranty; Remedies; Limitations. SCC warrants that if any Goods are found by an authorized representative of SCC not to be of good material or workmanship within one year of the date of shipments SCC will, at its option after inspection by an authorized representative, replace any defective Good or pay the reasonable cost of replacement for any such defective Goods, provided that written notice of the defect is given to SCC within 30 days of the appearance of such defect.

  • Page 13: Technical Service

    TECHNICAL SERVICE STRUCTURAL CONCEPTS CORPORATION TECHNICAL SERVICE DEPARTMENT 1.800.433.9489 888 E. Porter Road · Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com...
