Deliverables

Andromeda XZU90 module
Andromeda XZU90 module documentation, available via download:
Andromeda XZU90 Module User Manual (this document)
Andromeda XZU90 Module Reference Design [2]
Andromeda XZU90 Module IO Net Length Excel Sheet [3]
Andromeda XZU90 Module FPGA Pinout Excel Sheet [4]
Andromeda XZU90 Module User Schematics (PDF) [5]
Andromeda XZU90 Module Known Issues and Changes [6]
Andromeda XZU90 Module Footprint (Altium) [7]
Andromeda XZU90 Module 3D Model (PDF) [8]
Andromeda XZU90 Module STEP 3D Model [9]
Andromeda Module Pin Connection Guidelines [10]
Andromeda Master Pinout [11]
Enclustra Build Environment [12] (Linux build environment; refer to Section 1.3.2 for details)
Enclustra Build Environment How-To Guide [13]
Petalinux BSP and Documentation [14]
1.3.1

Reference Design

The Andromeda XZU90 module reference design features an example configuration for the Zynq Ultra-
Scale+ MPSoC device, together with an example top level HDL file for the user logic.
A number of software applications are available for the reference design, that show how to initialize the
peripheral controllers and how to access the external devices. Pre-compiled binaries are included in the
archive, so that the user can easily check that the hardware is functional.
The reference design can be downloaded from Github: https://github.com/enclustra.
1.3.2

Enclustra Build Environment

The Enclustra Build Environment (EBE) [12] enables the user to quickly set up and run Linux on any En-
clustra SoC module or system board. It allows the user to choose the desired target, and download all
the required binaries, such as bitstream and FSBL. It downloads and compiles all required software, such
as U-Boot, Linux, and BusyBox based root file system.
The Enclustra Build Environment features a graphical user interface (GUI) and a command line interface
(CLI) that facilitates the automatic build flow.
The Enclustra Build Environment How-To Guide [13] describes in more detail how to use the EBE to cus-
tomize the provided software for the user application. The document provides information on the con-
figuration options for U-boot, Linux kernel and Buildroot, debugging possibilities for Linux applications,
customization of device trees and integration of existing or new kernel drivers.
1.3.3

Petalinux BSP

The Enclustra Petalinux BSPs enable the user to quickly set up a Petalinux project and to run Linux on the
Enclustra SoC module or system board.
The documentation [14] describes the build process in detail and allows a user without Petalinux knowl-
edge to build and run the desired design on the target hardware.
