4.2.2

Preparing the Hardware

Step Description
1 Remove the power supply from the Mars ST3 base board (see label
2 Enable the SD card boot mode by setting the configuration DIP switches on the Mars ST3 base
board as follows (see labels
CFG = [1: OFF, 2: OFF, 3: ON, 4: OFF]
Table 13: Preparing the Hardware for SD Card Boot Mode Step-by-Step Guide
4.2.3

Programming the SD Card

Step Description
1 Write the Xilinx SD card boot image to a FAT32 formatted SD card
1. Insert the SD card into the SD card slot of your computer
2. Copy the boot image generated for your application to your SD card (directly in the root
directory).
Note that the name of the image must be preserved.
Table 14: Programming the SD Card for SD Card Boot Mode Step-by-Step Guide
4.2.4

Booting from the SD Card

Step Description
1 Insert the SD card into the SD card slot of the Mars ST3 base board (see label
2).
2 Power on the Mars ST3 base board (see label
Table 15: Booting from the SD Card Step-by-Step Guide
D-0000-489-003
CFG in Figure 2):
12 V DC
22 / 25
12 V DC
SD Card
in Figure 2).
Version 2022.1_v2.0.1, 15.10.2022
in Figure 2).
in Figure
