Figure 8: QSPI Flash Programming Settings in Vivado

Warning!

Some Vivado and Vitis tool versions are reporting problems when configuring certain SoC devices or

when using particular boot modes. Please try different tool versions and check the Xilinx documenta-

tion and forums for help on the reported issue.

4.1.3

Booting from the QSPI Flash

Step

Description

Check that the hardware configuration is done according to Section 4.1.1.

Press the power-on reset button (see label

Table 12: Booting from the QSPI Flash Step-by-Step Guide

4.2

4.2.1

Please refer to Section 4.0.1 describing the steps required to generate a boot image.

D-0000-489-003

POR

in Figure 2) and release it after a second.

21 / 25

Version 2022.1_v2.0.1, 15.10.2022
