Deliverables

Mercury+ PE3 base board
Mercury+ PE3 base board documentation, available via download:
Mercury+ PE3 Base Board User Manual ﴾this document﴿
Mercury+ PE3 Base Board IO Net Length Excel Sheet [2]
Mercury+ PE3 Base Board User Schematic ﴾PDF﴿ [3]
Mercury+ PE3 Base Board Known Issues and Changes [4]
Mercury+ PE3 Base Board 3D Model ﴾PDF﴿ [5]
Mercury+ PE3 Base Board 3D Model ﴾STEP﴿ [6]
Mercury Mars Module Pin Connection Guidelines [7]
Mercury Master Pinout [8]
Additional resources, available online:
Enclustra I2C Application Note [9]
1.3

Accessories

The following accessories are not included in the Mercury+ PE3 base board, but are required to use it.
Mercury FPGA or SoC module
12 V DC/3.5 A power supply
USB 2.0 A to micro‐B USB cable
