Before changing the position of the I/O voltage selection jumpers
Before removing the Mercury or Mercury+ module
Before connecting or disconnecting peripherals to ANIOS and I/O connectors
Before connecting or disconnecting FMC cards
Before connecting peripherals, make sure that the corresponding VCC_IO voltage is properly set.
The operating conditions for the Mercury+ PE3 base board and mounted module must conform to the
values given in Section 7, and in the relevant section from the Mercury or Mercury+ module user manual.
Tip
The Mercury+ PE3 base board must be used in combination with a Mercury or Mercury+ module. Using
the board without module will cause the "FAIL" LED to turn on. Refer to Section
D‐0000‐420‐001
9 /
63
6.7
for details.
Version 03, 11.07.2024
