Step

Description

Optional - alternatively, Enclustra Module Configuration Tool (MCT) [5] can be used to pro-

gram the QSPI flash. Note that the .mcs format is not supported.

Close all other tools that may be connected to the FTDI device (Vivado Hardware Manager,

Vitis, UART terminal).

Before programming the QSPI flash from MCT, make sure the hardware configuration on the

Mars PM3 base board is done according to 4.1.1

In order to see the output in the UART terminal, close the MCT tool after QSPI flash program-

ming and disconnect and reconnect the USB cable from the board and the UART terminal.

Table 10: Programming the QSPI Flash for QSPI Flash Boot Mode Step-by-Step Guide

Figure 7: QSPI Flash Programming Settings in Vitis

D-0000-492-002

19 / 24

Version 2022.1_v1.0.2, 04.01.2023
