Enclustra Mars AX3 User Manual page 18

Step Description
1 Program the boot image from Xilinx Vitis 2022.1 (see Figure 7):
1. Right click on the system project of the application in the Project Explorer
2. Select Program Flash
3. For Image File select the generated .bit, .bin or .mcs file
4. For Flash Type select s25fl512s-spi-x1_x2_x4
5. Hit Program and wait for completion
The settings in the pictures are for reference only. Note that the configuration file must be
selected according to your application.
2* Optional - if Vitis returns errors during flash programming or if the system does not boot
properly, another option is to use Vivado to program the QSPI flash.
1. Flow
2. Click on Open target
3. Right click on the corresponding FPGA device in the left bar
ory Device (see Figure 8)
(a) For Select Configuration Memory Part choose the memory part according to the
Mars AX3 FPGA Module User Manual [3], part type single.
This is in most cases s25fl512s-spi-x1_x2_x4.
(b) Hit OK
4. In Program Configuration Memory Device window (see Figure 9):
(a) For Configuration file select the boot image generated as described in Section 4.0.1.
Note that Vivado only accepts .bin and .mcs file formats.
(b) In Program Operations section:
The settings in the pictures are for reference only. Note that the memory part and the config-
uration file must be selected according to your application.
Continued on next page...
D-0000-492-002
Open Hardware Manager
Auto Connect
For Address Range select Entire Configuration Memory Device
Enable checkboxes Erase, Program and Verify
Hit OK and wait for completion
18 / 24
Add Configuration Mem-
Version 2022.1_v1.0.2, 04.01.2023
