4: Installation

4.1: Before installation

Connecting the device in a manner inconsistent with this manual
!
can cause risk to health, life or material damage.
• Don't power the device before fully assembling it in the protected
environment
• Check operating/maintenance manual of the device you want to control, to
make sure the connection is safe and allowed
• Connect only in accordance with the diagram
• Always use the same power source for L an IN terminals
• Check operating/maintenance manual for device your want to control to
make sure the connection is correct and safe
• Don't connect devices which are not compliant with the specification or
relevant safety standards.
Notes for figures:
S1 – terminal for the 1
S2 – terminal for the 2
Q/Q1 – output terminal of the 1
Q2 – output terminal of the 2
IN – input terminal for both channels
L – terminal for a live wire
N – terminal for a neutral wire
B – maintenance button
1 – device/system housing
2 – electrical device
button
st
button
nd
channel
st
channel
nd
7
InstallatIon
