7: Operating the device

7.1: Controlling channels with inputs

Momentary switch (parameter 20 set to 0):
1x click – change the state of the channel to the opposite one
Toggle switch without memory (parameter 20 set to 1):
1x switch – change the state of the channel to the state of the switch (OFF if
contacts opened, ON if contacts closed)
Toggle switch with memory (parameter 20 set to 2):
1x switch – change the state of the channel to the opposite one
By default S1 input controls the 1
i
trols the 2
eters 24 and 25.
By default outputs are set to NO (normally open).
i
It means the contacts is opened when turned off and closed
when turned on. It can be switched to NC (normally closed), which
means the contacts is closed when turned off and opened when
turned on using parameters 162/163.

7.2: Visual indications

The built-in LED light shows current device status.
After powering the device:
• Green – device added to a Z-Wave network (non-secure, S0, S2 non-au-
thenticated mode)
• Magenta – device added to a Z-Wave network (Security S2 Authenticated
mode)
• Red – device not added to a Z-Wave network
Update:
• Blinking cyan – update in progress
• Green – update successful
• Red – update not successful
Menu:
• Blinking green – entering the menu (added as non-secure, S0, S2
non-authenticated)
• Blinking magenta – entering the menu (added as Security S2 Authenticated)
channel if present. It can be changed using param-
nd
channel and S2 input con-
st
