FIBARO SMART MODULE Operating Manual page 24

24
confIguratIon
159. S2 input – Switch ON value sent to 3
This parameter defines value sent with the Switch ON
Description command to devices in the 3
using S2 input.
Parameter size 2B
Default value 255
Available
0-99 or 255
values
160. S2 input – Switch OFF value sent to 3
This parameter defines value sent with Switch OFF com-
Description mand to devices in the 3
S2 input.
Parameter size 2B
Default value 0
Available
0-99 or 255
values
161. S2 input – Double Click value sent to 3
This parameter defines value sent with Double Click com-
Description
mand to devices in the 3
S2 input.
Parameter size 2B
Default value 99
Available
0-99 or 255
values
162.
Description This parameter determines type of Q/Q1 output.
Parameter size 1B
Default value 0 (Normally Open)
0 – NO (Normally Open)
Available
values
1 – NC (Normally Closed)
163.
Description This parameter determines type of Q/Q1 output.
Parameter size 1B
Default value 0 (Normally Open)
Q/Q1 output type
Q2 output type
Only in Double Smart Module
association group
rd
association group when
rd
association group
rd
association group when using
rd
association group
rd
association group when using
rd
