FIBARO SMART MODULE Operating Manual page 20

20
Available
34.
Description
Parameter size 4B
Default value
Available
35.
Description
Parameter size 2B
Default value 600 (10 min)
Available
40.
Description
Parameter size 1B
Default value 15 (all active)
confIguratIon
1B [MSB] – Notification Type
2B – Notification Status
3B – Event/State Parameters
values
4B [LSB] – action:
0x00 – no action, 0x01 – turn ON, 0x02 – turn OFF, 0x03
– turn ON/OFF continuously
This parameter determines to which alarm frames and
how the device should react. The parameters consist of 4
bytes, three most significant bytes are set according to the
official Z-Wave protocol specification.
[0x04, 0xFF, 0x00, 0x00]
(Heat Alarm, any notification, no action)
1B [MSB] – Notification Type
2B – Notification Status
3B – Event/State Parameters
values
4B [LSB] – action:
0x00 – no action, 0x01 – turn ON, 0x02 – turn OFF, 0x03
– turn ON/OFF continuously
This parameter defines duration of alarm sequence. When
time set with this parameter elapses, alarm is cancelled,
LED frame and relay restore normal operation, but don't
recover state from before the alarm.
0 – infinite
values
1-32400 (1 s-9 h, 1 s step) – duration
This parameter determines which actions result in send-
ing scene IDs assigned to them. Values can be combined
(e.g. 1+2=3 means that scenes for single and double click
are sent).
Enabling scenes for triple click disables entering the device
in learning mode by triple clicking.
Alarm configuration - 5
Alarm configuration – duration
S1 input – scenes sent
slot
th
