FIBARO SMART MODULE Operating Manual page 18

18
Available
24.
Description
Parameter size 1B
Default value 0 (default)
Available
25.
Description
Parameter size 1B
Default value 0 (default)
Available
30.
Description
Parameter size 4B
Default value [0x00, 0x00, 0x00, 0x00] (disabled)
Available
confIguratIon
0 – momentary switch
2 – toggle switch (contact closed - ON, contact opened
- OFF)
values
3 – toggle switch (device changes status when switch
changes status)
This parameter enables reversing operation of S1 and S2
inputs without changing the wiring. Use in case of incorrect
wiring.
0 – default (S1 - 1st channel, S2 - 2nd channel)
values
1 – reversed (S1 - 2nd channel, S2 - 1st channel)
Only in Double Smart Module
This parameter enables reversing operation of Q1 and Q2
outputs without changing the wiring. Use in case of incor-
rect wiring.
0 – default (Q1 - 1st channel, Q2 - 2nd channel)
values
1 – reversed (Q1 - 2nd channel, Q2 - 1st channel)
This parameter determines to which alarm frames and
how the device should react. The parameters consist of 4
bytes, three most significant bytes are set according to the
official Z-Wave protocol specification.
1B [MSB] – Notification Type
2B – Notification Status
3B – Event/State Parameters
values
4B [LSB] – action:
0x00 – no action, 0x01 – turn ON, 0x02 – turn OFF, 0x03
– turn ON/OFF continuously
Inputs orientation
Outputs orientation
Alarm configuration - 1 slot
st
