Page 1: Table Of Contents
O P E R A T I N G M A N U A L FIBARO SINGLE SWITCH FGBHS-213 CONTENTS #1: Description and features #6: Functionality #2: Supported loads #7: Configurable parameters #3: Installation #8: Specifications #4: Pairing the accessory... - Page 2 Fibar Group S.A. will not be held responsible for any loss or damage resulting from not following the instructions of operating manual. Danger of electrocution! FIBARO Single Switch is designed to operate in electrical home installation. Faulty connection or use may result in fire or electric shock.
-
Page 3: 1: Description And Features
#1: Description and features FIBARO Single Switch is designed to be installed in standard wall switch boxes or anywhere else where it is necessary to control electric devices. FIBARO Single Switch allows to control connected devices either via HomeKit technology (using Bluetooth® low energy) or via a switch connected directly to it and is equipped with active power and energy consumption metering functionality. -
Page 4: 2: Supported Loads
#2: Supported loads The Single Switch may operate under the following loads: • Conventional incandescent light sources, • Halogen light sources, • Electrical appliances which power consumption does not exceed the limit for a specified device, • loads up to 8A rated current. Applied load and the Single Switch itself may be damaged if the applied load is inconsistent with the technical speci- fications! -
Page 5: 3: Installation
#3: Installation Connecting the Single Switch in a manner inconsistent with this manual may cause risk to health, life or material damage. When connecting the Single Switch act in accordance with the following rules: • Connect only in accordance with one of the diagrams, •... - Page 6 Installation of the Single Switch: NOTE 1. Switch off the mains voltage (disable the fuse). Switch connected to 2. Open the wall switch box. the S1 terminal is a master switch. It acti- 3. Connect with one of following the diagrams for appropriate vates the basic func- device: tionality of the device...
-
Page 7: 4: Pairing The Accessory
#4: Pairing the accessory 1. Open the Settings app on your iOS device. 2. Go to the Bluetooth® section, and turn the Bluetooth® on. 3. Place the accessory next to your iOS device. 4. Open a HomeKit compatible app of your choosing on your iOS device. -
Page 8: 5: Reset
#5: Reset Resetting the Single Switch to factory defaults: Reset procedure allows to restore the accessory back to its factory settings including HomeKit pairing. 1. Open the wall switch box. 2. Press and hold the button. WARNING! Button Danger electro- cution, take precau- tions to avoid electric shock! -
Page 9: 6: Functionality
#6: Functionality Power consumption monitoring: NOTE The Single Switch measure current active power consumption and Power consumption reports it to your iOS device. reports are sent not more frequently than new power consumption report is sent: every 10 second. • if current power changed by at least 20% compared to last reported, •... - Page 10 Malfunction detection: NOTE The Single Switch detects some malfunctions and reports them to Status fault values your iOS device. may be combined, e.g. 1+2=3 means over- Every malfunction is sent using Status Fault with code assigned to heat and overload oc- every event: cured.
-
Page 11: 7: Configurable Parameters
#7: Configurable parameters 1. Type of connected switch This parameter allows to select type of wall switch connected to the device. Available settings: 0 – momentary switch 1 – toggle switch (contact closed - On, contact opened - OFF) 2 – toggle switch (device changes status when switch changes status) 1 (toggle switch - synced) Default setting:... -
Page 12: 8: Specifications
#8: Specifications Power supply: 100-240V~ 50/60 Hz Rated load current: Operating temperature: 0-35°C For installation in boxes: Ø ≥ 50mm, depth ≥ 60mm Overcurrent protection: required external 10A circuit breaker Radio protocol: Bluetooth® low energy Radio signal power: EIRP up to 10dBm Radio frequency: 2.4 GHz Eu directives compliance:... -
Page 13: 9: Regulations
All information, including, but not limited to, information regarding the features, functionality, and/or other product specification are subject to change without notice. Fibaro reserves all rights to revise or update its products, software, or documentation without any obligation to no- tify any individual or entity.
