Caution
The BIDI modules must be used in pairs. For example, if you install the GE-SFP-LX20-SM1310-BIDI on one
end, you must install the GE-SFP-LX20-SM1550-BIDI on the other end.
6.2.2

SFP+ Transceiver Modules

Table 6-5 Models and Specifications of SFP+ Optical Transceiver Modules
Model
XG-SFP-SR-
MM850
XG-SR-
MM850
SFP+MM850
XG-SFP-LR-
SM1270-BIDI
XG-SFP-LR-
SM1330-BIDI
XG-LR-
SM1310
SFP+SM1310
XG-SFP-LR-
SM1310
XG-eSFP-LR-
SM1310
XG-SFP-ER-
SM1550
XG-SFP-ZR-
SM1550
SFP-S4-
R1000P1 v2
SFP-S1-
R1000P1
Optical Cable
Wavelength
(nm)
Type
850 Yes
850 Yes
850 Yes
1270 No
1330 No
1310 Yes
1310 Yes
1310 Yes
1310 Yes
1550 Yes
1550 Yes
1310 Yes
1310 Yes
Transmit Power
DDM
(dBm)
(Yes/No)
Min.
–7.3
MMF
–7.3
MMF
–7.3
MMF
–6.5
SMF
–6.5
SMF
–8.2
SMF
–8.2
SMF
–8.2
SMF
–8.2
SMF
–4.7
SMF
SMF 0
–8.2
SMF
–8.2
SMF
38
Receive Power
(dBm)
Max. Min. Max.
–1 –9.9 –1
–1 –9.9 –1
–1 –9.9 –1
–14.4
0.5 0.5
–14.4
0.5 0.5
–14.4
0.5 0.5
–14.4
0.5 0.5
–14.4
0.5 0.5
–14.4
0.5 0.5
–11.3 –1
4
–24 –7
4
–14.4
0.5 0.5
–14.4
0.5 0.5
Appendix
