No. Item
Management
port LED
4
Reset button
5
6 Fan module
Power module
status LED
7
Power module
8
1.2.3

Hardware Specifications

Table 1-2 Hardware Specifications of the RG-NBF6002M
Model
CPU
Flash Memory
Description
device is starting up.
Blinking green (fast blinking: on for 0.25s and off for 0.25s): The device is
restored to factory settings.
Blinking green (slow blinking: on for 2s and off for 0.25s): The device is
not connected to Ruijie Cloud.
Blinking yellow (on for 1s and off for 1s): The device temperature reaches
the warning threshold; the temperature cannot be read; there is another
non-critical problem; or performance has deteriorated.
Blinking red (one long blink and one short blink: on for 1s, off for 1s, on
for 0.25s, and off for 1.75s): The power supply is faulty; a line card is
faulty; a line card conflict occurs; or the line card is hot-swapped.
Blinking red (one long blink, three short blinks: on for 1s, off for 1s, on for
0.25s, off for 0.25s, on for 0.25s, off for 0.25s, on for 0.25s, off for 1.75s,
repeated): The main program is lost or damaged; other hardware faulty
has occurred; or a specific function is abnormal.
Off: The device is not receiving power.
A 10/100/1000BASE-T port LED.
Solid green: A link is set up on the port at a rate of 1000 Mbps.
Blinking green: A link is set up on the port at a rate of 1000 Mbps, and
data is transmitted on the link.
Off: No link is set up on the port.
Press and hold for less than 2s: All modules will be reset.
Press and hold for more than 5s: All modules will be reset, the initial
password will be restored, and the supervisor module will be restored to
factory settings and the configuration backup file will be saved. After the
supervisor module is restarted, you can choose "Delete backup" or
"Restore backup (with default password)" when logging in to the web
interface of the device. If you do not log in to the web interface, the
supervisor module is restored to factory settings.
Press and hold for 2s to 5s: No action is triggered.
Three fans for system cooling.
PWR1 and PWR2 power module status LED
Solid green: The power module is normal.
Solid red: The power module is faulty.
Off: The system has no power supply.
Two power supply slots: PWR1 and PWR2.
Install the power modules before connecting the AC power cord.
Power modules can work in 1+1 redundancy mode.
RG-NBF6002M
Built-in CPU, single-core processor, clock speed of 1 GHz
256 MB
4
