- Page 1 RG-NBS1805C-P / RG-NBS1809C-P Quick Installation Guide 交换机快速安装指南...
-
Page 2: Installing The Switch
锐捷以太网 PoE 供电交换机快速安装指南 Quick Installation Guide of Ruijie Ethernet PoE Switches 本指南适用于 RG-NBS1805C-P 和 RG-NBS1809C-P。 This quick installation guide applies to RG-NBS1805C-P and RG-NBS1809C-P. 1. 设备安装 Installing the switch 安装到墙壁 Wall mounting *仅适用于 RG-NBS1805C-P。 *It applies to RG-NBS1805C-P only. 第一步：根据交换机底面壁挂孔位置，在墙上定位并钻孔。... - Page 3 安装到桌面 Desktop mounting 将交换机正面朝上置于足够大且干净平稳的桌面上即可。 Place the switch face up on a stable and flat desktop.
-
Page 4: Connecting Your Devices
2. 设备连接 Connecting your devices 成换替图中图图时换排 批注 [王凛1]: RG-NBS1809 交换机 。 *PoE 供电交换机图示以 RG-NBS1809C-P 为例。 成换替图中图图时换排 批注 [梁婷2]: RG-NBS1809 交换机 。... - Page 5 请参考下表检查设备连接是否正确或调节交换机工作模式。 Refer to the following table to check if the device connection is correct, or to transfer working mode of the switch. 指示灯/开关 说明 长亮：交换机通电正常。 熄灭：交换机未通电或通电异常。 长亮：端口已连接受电设备，并供电正常。 闪烁：端口接入的受电设备的功耗过大。 熄灭：端口未连接受电设备，或没有供电。 长亮：端口已连接。 Link/Act 闪烁：端口正在传输数据。 熄灭：端口未连接，或连接异常。 工作模式拨码开关，用于切换交换机模式。 Default：默认模式。此模式下，交换机 PoE 口的速率最高可协商为 100Mbps。 *仅适用于 RG-NBS1805C-P...
- Page 6 Default: Default mode of the switch. In this mode, the maximum data rate of a single PoE port can be 100 Mbps. * Only for RG-NBS1805C-P Extend: In this mode, the maximum data rate of a single PoE port reduces to 10 Mbps, but maximum transmission distance is 250 meters.
- Page 7 规格参数 产品型号 RG-NBS1805C-P RG-NBS1809C-P 10/100Mbps RJ45 端口 端口 10/100/1000M 无 RJ45 工作模式 网络延长 端口 VLAN 交换模式 存储转发 MAC 地址表 性能 MAC 地址学习 自动学习、自动老化 背板带宽 1.0Gbps 3.6Gbps PoE 供电端口 PoE 供电标准 IEEE 802.3af、IEEE 802.3at PoE 供 PoE 供电电芯 8 芯供电（1 2 4 5 为+，3 6 7 8 为-）...
-
Page 8: Specifications
安规 GB4943-2011 Specifications Model RG-NBS1805C-P RG-NBS1809C-P 10/100 Mbps RJ45 port Interface 10/100/1000 Mbps RJ45 port Working mode Extend Port VLAN Store-and-forward Supported Address Table Feature Address Self-learning, auto-aging Learning Backplane 1.0 Gbps 3.6 Gbps Bandwidth PoE port 1 - 4... - Page 9 Differential mode: 2kV Differential mode: 2kV Temperature: 0°C - 40°C Temperature: 0°C - 40°C Working Environment Humidity: 10% - 90% RH (no Humidity: 10% - 90% RH (no condensing) condensing) Temperature: -40°C - 70°C Temperature: -40°C - 70°C Storage Environment Humidity: 5% - 90% RH (no Humidity: 5% - 90% RH (no condensing) condensing)
- Page 10 如需了解产品及安装方面的更多信息，请登录锐捷网络网站 www.ruijie.com.cn For more information about the product and installation procedures, log in to www.ruijie.com.cn 锐捷网络股份有限公司 换权所有，保留一切权利 Copyright @ ruijie networks Co., Ltd. RUIJIE NETWORKS CO., LTD. Ruijie Science and Technology Park, Juyuanzhou, No. 618, Jinshan Road, Fuzhou Technical Support: http://bbs.ruijiery.com Technical Support Hotline: +86-400-100-0078(China) Website: http://www.ruijiery.com...
