Installation Guide
SDRAM
Number of
Line Card
Slots
Line Cards
Hot Swapping
Power Module
Power Module
Redundancy
Fan Module
Certification
Altitude
Operating
Temperature
Storage
Temperature
Operating
Humidity
MTBF
Noise
Weight
Dimensions (W
x D x H)
Note
The weight refers exclusively to the chassis. The overall weight of the device varies depending on the installed
line cards.
Warning
Operation of this equipment in a residential environment could cause radio interference.
DDRIII 1 GB
2
MF6000M-24GT2XS
MF6000M -16GT8SFP2XS
MF6000M-16FS8GT2XS
Supported by power modules, but not by line cards.
RG-PA150I-FS: 100 V AC to 240 V AC, 150 W
Supported. The power modules must be of the same model. (To improve the stability and
reliability of the entire system, 1+1 power supply redundancy is recommended.)
Fixed fan
CE
Long-term operating altitude: 50° C at 1800 m (5905.512 ft.). At altitudes between
1800 m (5905.512 ft.) and 5000 m (16404.2 ft.), the temperature decreases by 1° C
(33.8° F) for every 220 m (721.78 ft.) increase in altitude.
Maximum operating altitude: 5000 m (16404.2 ft.)
Maximum storage altitude: 5000 m (16404.2 ft.)
0° C to 50° C (32° F to 122° F)
–40° C to +70° C (–40° F to +156° F)
10% to 90% RH (non-condensing)
> 200,000 hours
≤ 60 dB at 25º C
5.4 kg (11.90 lbs.) (excluding line cards)
442 mm x 460 mm x 44 mm (17.47 in. x 18.17 in. x 1.74 in.)
5
Overview
