- Page 1 Ruijie Reyee RG-NBF2100S Series e-Lighten Access Switches Installation Guide Document Version: V1.1 Date: September 6, 2024 Copyright © 2024 Ruijie Networks...
- Page 2 Ruijie Networks reserves the right to modify the content of the document without any notice or prompt. This manual is designed merely as a user guide. Ruijie Networks has tried its best to ensure the accuracy and reliability of the content when compiling this manual, but it does not guarantee that the content of the manual is completely free of errors or omissions, and all the information in this manual does not constitute any explicit or implicit warranties.
-
Page 3: Preface
Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support The official website of Ruijie Reyee: https://reyee.ruijie.com Technical Support Website: https://reyee.ruijie.com/en-global/support Case Portal: https://www.ruijienetworks.com/support/caseportal Community: https://community.ruijienetworks.com... - Page 4 Note This manual provides installation steps, troubleshooting, technical specifications, and usage guidelines for cables and connectors. It is intended for users who want to understand the above and have extensive experience in network deployment and management, and assume that users are familiar with related terms and concepts.
-
Page 5: Table Of Contents
Contents Preface ..............................I 1 Overview ............................1 1.1 About the RG-NBF2100S Series Switches ................1 1.2 Package Contents........................2 1.2.1 Package Contents of the RG-NBF2100S-8GT1SC-P ........... 2 1.2.2 Package Contents of the RG-NBF2100S-8GT1SC ............2 1.2.3 Package Contents of the RG-NBF2100S-16GT1SC-P ..........3 1.3 Product Appearance ........................ - Page 6 2.2.1 Floor Loading ....................... 15 2.2.2 Airflow ........................... 15 2.2.3 Space ........................... 15 2.2.4 Temperature and Humidity ................... 15 2.2.5 Cleanliness ........................16 2.2.6 Grounding ........................17 2.2.7 Anti-Electromagnetic Interference................17 2.2.8 Surge Protection ......................17 2.2.9 EMI ..........................18 2.2.10 Installation Site ......................
- Page 7 4 Log in to the Web UI......................... 26 5 Troubleshooting ..........................27 5.1 Troubleshooting Flowchart ...................... 27 5.2 Common Faults ........................27 5.2.1 Forgot or Lost the System Login Password..............27 5.2.2 System Status LED Is Off for a Long Time ..............27 5.2.3 Only Partial PoE Ports Can Supply Power ..............
-
Page 8: Overview
Installation Guide Overview Overview About the RG-NBF2100S Series Switches The Reyee e-Lighten Solution is a network product solution based on existing Ethernet technology integrating PON technology and passive optical splitting features. The components include: e-Lighten core switch (OLT): As a core switch, it has the Layer 3 data forwarding capability. It provides PON ports that can be connected to e-Lighten access switches and e-Lighten access points (APs) to achieve data interconnection. -
Page 9: Package Contents
Installation Guide Overview 10/100/1000BASE-T Ethernet Ports SC PON Power Model with Auto-negotiation Ports Ports Module RG-NBF2100S-16GT1SC-P input Package Contents Note The package contents are subject to the purchase contract, and actual delivery may vary. Please check the items carefully against the package contents or purchase contract. If you have any questions, please contact your distributor. -
Page 10: Package Contents Of The Rg-Nbf2100S-16Gt1Sc-P
Fast blinking green: 1. The device is starting up. 2. The device is restoring factory settings. 3. The device version is being upgraded. System status LED Solid green: The device is working properly. Slow blinking green: The device is not connected to Ruijie Cloud or a loop occurs. - Page 11 Installation Guide Overview Item Description Used to restart the device or restore factory settings. Press and hold the button for less than 2 seconds to restart the system. Reset button Press and hold the button for more than 5 seconds until the system status LED blinks.
-
Page 12: Appearance Of The Rg-Nbf2100S-8Gt1Sc
System status LED upgraded. Solid green: The device is working properly. Slow blinking green: The device is not connected to Ruijie Cloud or a loop occurs. Used to restart the device or restore factory settings. Press and hold the button for less than 2 seconds to restart the system. -
Page 13: Appearance Of The Rg-Nbf2100S-16Gt1Sc-P
Installation Guide Overview Item Description SC PON port GE SC PON uplink port. Slow blinking green: The device is registered successfully. Slow blinking red: No optical input or the optical cable is not SC port status LED inserted. Slow blinking yellow: The device is registering. Nameplate Located at the bottom of the front panel. - Page 14 3. The device version is being upgraded. System status LED Solid green: The device is working properly. Slow blinking green: The device is not connected to Ruijie Cloud or a loop occurs. Off: The switch is not connected to a power supply. Switch Used to change the status LED mode of the ports on the front panel.
-
Page 15: Hardware Specifications
Installation Guide Overview Figure 1-7 Rear Panel of the RG-NBF2100S-16GT1SC-P Table 1-10 Components on the Rear Panel of the RG-NBF2100S-16GT1SC-P Item Description Grounding stud Used to secure the grounding lug to connect the chassis to an earth ground. Hardware Specifications 1.4.1 Hardware Specifications of the RG-NBF2100S-8GT1SC-P Table 1-11... - Page 16 Installation Guide Overview Adapter AC input: Rated voltage range: 186 V AC to 240 V AC Maximum voltage range: 186 V AC to 240 V AC Power Module Frequency: 50 Hz/60 Hz Rated current: 1.5 A Power cord requirement: 10 A power cord Inner diameter: 2.1 mm (0.08 in.) Outer diameter: 5.5 mm (0.22 in.) Adapter DC Power...
-
Page 17: Hardware Specifications Of The Rg-Nbf2100S-8Gt1Sc
Installation Guide Overview 1.4.2 Hardware Specifications of the RG-NBF2100S-8GT1SC Table 1-12 Hardware Specifications of the RG-NBF2100S-8GT1SC Model RG-NBF2100S-8GT1SC The optical power of the ONU's SC port should be within the range of –28 dBm to –8 dBm. If the power is out of this range, the device may have an exception or be damaged. -
Page 18: Hardware Specifications Of The Rg-Nbf2100S-16Gt1Sc-P
Installation Guide Overview Operating Humidity 10% RH to 90% RH (non-condensing) Storage Humidity 5% RH to 95% RH (non-condensing) Fanless Temperature Alarm Not supported Certification 202 mm x 108 mm x 28 mm (7.95 in. x 4.25 in. x 1.10 in.) Dimensions (W x D x H) Weight 0.50 kg (1.10 lbs.) - Page 19 Installation Guide Overview Adapter AC input: Rated voltage range: 100 V AC to 240 V AC Power Module Maximum voltage range: 90 V AC to 264 V AC Frequency: 50 Hz/60 Hz Rated current: Vout = 54 V (4.7 A), Vout = 12 V (3 A) Ground-Leakage ≤...
-
Page 20: Preparing For Installation
Installation Guide Preparing for Installation Preparing for Installation Safety Guidelines Note To avoid personal injury or equipment damage, review the safety guidelines in this chapter before you begin the installation. The following safety guidelines may not include all the potentially hazardous situations. 2.1.1 General Precautions ... -
Page 21: Preventing Esd Damage
Installation Guide Preparing for Installation Locate the emergency power supply switch in the room before installation. In the case of an accident, cut off the power supply immediately. Carefully inspect the equipment and the environment before powering on or off the equipment. ... -
Page 22: Site Requirements
Installation Guide Preparing for Installation a dust cap to keep out dust and prevent it from burning your eyes. When an optical transceiver is in operation, do not look into its port after removing the optical fiber. Doing so may result in eye injury. -
Page 23: Cleanliness
Installation Guide Preparing for Installation electricity generation. This static electricity can pose a danger to the circuits inside the equipment. In a dry environment, static electricity is prone to occur and damage the internal circuits of the equipment. High temperature environments can be detrimental to the equipment, leading to reduced performance and a shorter service life. -
Page 24: Grounding
Installation Guide Preparing for Installation 2.2.6 Grounding A proper grounding system is crucial for ensuring stable and reliable operation of the equipment, as well as preventing lightning strikes and interference. To ensure proper grounding, carefully check the grounding conditions at the installation site according to the grounding specifications, and complete grounding properly based on the actual situation. -
Page 25: Emi
Installation Guide Preparing for Installation power strip, and then connect the equipment to the lightning protection power strip. This prevents high- voltage lightning from directly passing through the equipment over the mains supply AC power cord. Note The lightning protection power strip is not delivered with the equipment. Purchase it as required. ... -
Page 26: Tools
Installation Guide Preparing for Installation Figure 2-2 19-Inch Rack (3) The square-hole rack post is at least 180 mm (7.09 in.) from the front door, and the front door is at most 25 mm (0.98 in.) thick. This ensures an available clearance of at least 155 mm (6.10 in.). The rack depth (distance between front and rear doors) is at least 1000 mm (39.37 in.). -
Page 27: Installing The Switch
Installation Guide Installing the Switch Installing the Switch Caution Before installing the equipment, ensure that guidelines and requirements in Chapter 2 have been met. Precautions for Installation Pay attention to the following points during installation: Connect the power cords of different colors to the corresponding cable terminals. ... -
Page 28: Mounting A Switch On The Wall
Installation Guide Installing the Switch Figure 3-1 Installing Mounting Brackets on the RG-NBF2100S-16GT1SC-P (2) Place the switch horizontally in the rack and secure it to the rack using the M6 screws and matching cage nuts, which need to be prepared by yourself. Figure 3-2 Securing the RG-NBF2100S-16GT1SC-P to the Square Holes of the Rack 3.2.2... -
Page 29: Mounting A Switch On The Ceiling
Installation Guide Installing the Switch (1) Pull out the mounting plate of the switch, and use two M4 screws (which need to be prepared by yourself) to secure the switch to the wall. (2) Use the mounting brackets and two M4 screws (which need to be prepared by yourself) to secure the switch to the wall. -
Page 30: Installing A Switch On A Desktop
Installation Guide Installing the Switch Before mounting a switch on a ceiling, ensure that the ceiling can support the weight of the switch. Ensure that the length of the M4 screws prepared by yourself is longer than 10 mm (0.39 in.). (1) Pull out the mounting plate of the switch, and use two M4 screws (which need to be prepared by yourself) to secure the switch to the ceiling. -
Page 31: Connecting The Grounding Wire
Installation Guide Installing the Switch (2) Place the switch on the workbench and ensure adequate airflow around the switch. Connecting the Grounding Wire Warning To avoid personal injury and device damage, connect the switch to an earth ground properly. ... -
Page 32: Connecting The Power Cord
Installation Guide Installing the Switch chassis and the ground must be less than 1 Ω. Procedure: (1) Remove the ground screw on the rear panel of the device. (2) Use the removed ground screw to secure one end of the grounding wire to the chassis. Similarly, connect the other end of the grounding wire to the rack grounding cable or the equipment room grounding bar. -
Page 33: Log In To The Web Ui
Installation Guide Log in to the Web UI Log in to the Web UI (1) Connect the PC to the Ethernet port of the device using a cable. (2) Configure your PC with an IP address on the network of 10.44.77.XXX (Range of XXX: 1–255, excluding 200). -
Page 34: Troubleshooting
Check the device installation Check the power connection Check the LEDs status of the device Check the cable connection Contact technical support of Ruijie Networks Common Faults 5.2.1 Forgot or Lost the System Login Password Press and hold the reset button for more than 5 seconds to restore factory settings and reset the system login password. - Page 35 Installation Guide Troubleshooting Fault Symptom Possible Cause Solution Press and hold the reset button for more than The login password The login password is forgotten 5 seconds to reset your username and cannot be retrieved. after being configured. password. The system status LED Check whether the power socket in the No power is supplied to the is off after the switch is...
-
Page 36: Appendix
Installation Guide Appendix Appendix Ports, Connectors, and Media 6.1.1 1000BASE-T/100BASE-TX/10BASE-T Ports 1000BASE-T/100BASE-TX/10BASE-T ports are Ethernet ports with auto-negotiation of three speeds: 10 Mbps, 100 Mbps, and 1000 Mbps. They supports auto MDI/MDIX Crossover, and use RJ 45 connectors. Compliant with the IEEE 802.3ab standard, a 1000BASE-T port requires 100-ohm Category 5 or 5e unshielded twisted pair (UTP) or shielded twisted pair (STP) (recommended) cables, and supports a maximum distance of 100 meters (328 feet). -
Page 37: Pon Ports And Sc Ports
6.1.2 PON Ports and SC Ports Figure 6-3 shows the PON ports and SC ports on equipment in Ruijie Reyee e-Lighten Optical Solution. PON ports on the OLT require e-Lighten optical transceivers with SC/UPC connectors, which are connected to an optical splitter using single-mode fiber. - Page 38 Installation Guide Appendix lightning strikes. The surge protector power strip can be fixed on the rack, workbench, or wall in the equipment room by using cable ties and screws. AC power enters the equipment through the surge protector power strip. Figure 6-4 Installing an AC Power Lightning Arrester Description...
-
Page 39: Installing An Ethernet Port Lightning Arrester
Installation Guide Appendix Precautions: Make sure that the PE terminal of the power arrester is well grounded. After the AC power plug of the equipment is connected to the socket of the power arrester (lightning resistance socket), the surge protection function is implemented only if the RUN indicator is green and the ALARM indicator is OFF. - Page 40 Installation Guide Appendix Figure 6-5 Installing an Ethernet Port Lightning Arrester Device Description Ethernet cable for indoor connection Ethernet cable connected to the outdoor RJ45 port arrester (pasted on the enclosure) Ground cable of the arrester Grounding lug of the equipment RJ45 port adapter cable Power input Note...
-
Page 41: Recommended Cabling
Installation Guide Appendix need to be installed on all connection ports for the purpose of surge protection. Recommended Cabling When the device is installed in a standard 19-inch rack, route the cables through the cable management brackets. Top cabling or bottom cabling is adopted according to the actual situation in the equipment room. All conversion connectors should be placed at the bottom of the rack instead of outside the rack that is easily accessible. - Page 42 Installation Guide Appendix Figure 6-6 Binding Cables (I) Description In the rack, cables should not be wound up after being bundled. In the rack, cables should not bend after being bundled. In the rack, cables should be neatly and straightly bundled. ...
- Page 43 Installation Guide Appendix Figure 6-7 Binding Cables (II) When cables need to be bent, please bundle them up but do not tie them where the cables will be bent, as shown in Figure 6-8. Figure 6-8 Binding Cables (III) ...
-
Page 44: Site Selection
Installation Guide Appendix high-temperature cables should be used. When screw threads are used to fasten cable terminals, the anchor or screw must be tightly fastened, as shown in Figure 6-9. Figure 6-9 Cable Fastening ① Flat washer ③ Spring washer ②... -
Page 45: Cleaning The Connectors And End Faces Of Optical Cables
Installation Guide Appendix factory. The equipment room should be at least 2 km (1.24 miles) away from light pollution sources, such as the food factory and leather plant. If the pollution source is unavoidable, the equipment room should be located on the windward side of the pollution source perennially with advanced protection. ... - Page 46 Installation Guide Appendix Fiber-optic cleaning pens, also known as one-click fiber-optic cleaners, typically use anti-static resin materials, lint-free cleaning tip, and cleaning solution to ensure the product remains free from dust contamination. Available in 1.25 mm and 2.5 mm sizes, these pens are suitable for cleaning SC, FC, LC connectors, and more.
